207-06-75140 Komatsu Wiring Harness
Product name: Komatsu Wiring Harness
Part No: 207-06-75140 207-06-76111
Model Number:For PC400-7 PC400LC-7 PC200-7 PC200LC-7
Material:Lron+Rubber
Packing:PP bag inside, carton box outside
Payment Terms:Western Union, L/C, T/T, MoneyGram, D/A, D/P
MOQ:Acceptable trial order
Shipping Mode:By air, by sea, by express(Fedex, UPS, DHL, TNT, etc.)
Place of Origin:Guangdong, China
Brand name:COGENG
CertifiCATEEion:ISO9001
Supply :500PCS
Decompose pictures
Parts list
NO |
Number |
Name |
Qty |
1 |
207-06-76111 |
Wire Harness |
1 |
2 |
08020-20000 |
• Diode |
2 |
3 |
08041-00500 |
• Fuse, 5Amp. |
1 |
4 |
08041-01000 |
• Fuse, 10Amp. |
12 |
5 |
08041-02000 |
• Fuse, 20Amp. |
5 |
6 |
08041-03000 |
• Fuse, 30Amp. |
2 |
7 |
19M-06-31720 |
• Resistor |
1 |
8 |
20Y-06-31660 |
• Fusible Link, 30Amp. |
1 |
9 |
22U-06-11270 |
• Fusible Link, 65Amp. |
1 |
10 |
HM6400-0012 |
• Connector, Black |
2 |
|
HM6409-0071 |
• Connector, Black |
2 |
11 |
HM6400-0013 |
• Connector, Green |
2 |
|
HM6409-0072 |
• Connector, Green |
2 |
12 |
HM6440-0129 |
• Connector, Pink |
1 |
|
HM6440-0128 |
• Connector, Pink |
1 |
13 |
HM6400-0016 |
• Connector, Orange |
1 |
|
HM6409-0075 |
• Connector, Orange |
1 |
14 |
207-06-75140 |
Wire Harness |
1 |
15 |
08038-00035 |
Cap |
1 |
16 |
08088-30000 |
Switch |
1 |
17 |
01010-80830 |
Bolt |
2 |
18 |
01643-30823 |
Washer |
2 |
19 |
08038-00519 |
Cap |
2 |
20 |
207-06-75122 |
Bracket |
1 |
21 |
600-815-2170 |
Switch, Heater |
1 |
22 |
01010-80616 |
Bolt |
2 |
23 |
01643-30623 |
Washer |
2 |
24 |
08038-00519 |
Cap |
1 |
25 |
08038-02027 |
Cap |
2 |
26 |
08028-CD065 |
Cable, Ground |
1 |
27 |
08038-00035 |
Cap |
1 |
Installation decomposition diagram
