20Y-06-22711 Komatsu Wiring Harness
Product name: Komatsu Wiring Harness
Part No: 20Y-06-22711 20Y0622711
Model Number:For PC200-6 PC200-6Z PC200-6-H PC200LC-6H PC210-6 PC210LC-6 PC220-6 PC220LC-6 PC230-6 PC230LC-6
Material:Lron+Rubber
Packing:PP bag inside, carton box outside
Payment Terms:Western Union, L/C, T/T, MoneyGram, D/A, D/P
MOQ:Acceptable trial order
Shipping Mode:By air, by sea, by express(Fedex, UPS, DHL, TNT, etc.)
Place of Origin:Guangdong, China
Brand name:COGENG
CertifiCATEEion:ISO9001
Supply :500PCS
Decompose pictures
Parts list
| NO |
Number |
Name |
Qty |
| 1 |
20Y-06-22711 |
WIRING HARNESS |
1 |
|
20Y-06-15150 |
• FUSIBLE LINK |
2 |
| 2 |
113-899-7950 |
CLIP |
1 |
| 3 |
144-947-3490 |
SPACER |
1 |
| 4 |
01010-81245 |
BOLT |
1 |
| 5 |
01643-31232 |
WASHER |
1 |
| 6 |
20Y-06-21240 |
PLATE |
1 |
| 7 |
01010-81225 |
BOLT |
1 |
| 8 |
01643-31232 |
WASHER |
1 |
| 9 |
113-899-7950 |
CLIP |
1 |
| 10 |
01010-81225 |
BOLT |
1 |
| 11 |
01643-31232 |
WASHER |
1 |
| 12 |
08036-01014 |
CLIP |
1 |
| 13 |
01010-81225 |
BOLT |
1 |
| 14 |
01643-31232 |
WASHER |
1 |
| 15 |
113-899-7950 |
CLIP |
1 |
| 16 |
01010-81230 |
BOLT |
1 |
| 17 |
01643-31232 |
WASHER |
1 |
| 18 |
113-899-7950 |
CLIP |
2 |
| 19 |
01010-81225 |
BOLT |
2 |
| 20 |
01643-31232 |
WASHER |
2 |
| 21 |
113-899-7950 |
CLIP |
1 |
| 22 |
144-947-3490 |
SPACER |
1 |
| 23 |
01010-81245 |
BOLT |
1 |
| 24 |
01643-31232 |
WASHER |
1 |
| 25 |
208-06-19170 |
CLIP |
1 |
| 26 |
113-899-7950 |
CLIP |
1 |
| 27 |
04434-52712 |
CLIP |
2 |
| 28 |
01010-81225 |
BOLT |
4 |
| 29 |
01643-31232 |
WASHER |
4 |
| 30 |
20Y-06-21532 |
BRACKET |
1 |
| 31 |
01010-81225 |
BOLT |
2 |
| 32 |
01643-31232 |
WASHER |
2 |
| 33 |
08036-02514 |
CLIP |
1 |
| 34 |
01010-81225 |
BOLT |
1 |
| 35 |
01643-31232 |
WASHER |
1 |
| 36 |
08036-01814 |
CLIP |
1 |
| 37 |
01010-81225 |
BOLT |
1 |
| 38 |
01643-31232 |
WASHER |
1 |
| 39 |
08036-01814 |
CLIP |
1 |
| 40 |
08036-02514 |
CLIP |
1 |
| 41 |
01010-81225 |
BOLT |
2 |
| 42 |
01643-31232 |
WASHER |
2 |
| 43 |
08036-01814 |
CLIP |
1 |
| 44 |
01010-81225 |
BOLT |
1 |
| 45 |
01643-31232 |
WASHER |
1 |
| 46 |
08036-01414 |
CLIP |
2 |
| 47 |
01010-81225 |
BOLT |
2 |
| 48 |
01643-31232 |
WASHER |
2 |
Installation decomposition diagram
