4257164 John Deere Throttle Motor
Product name: John Deere Throttle Motor
Part No: 4257164
Model Number:For 192E 450LC 490E 550LC 750 790ELC 892ELC 892E 892EL 8926101
Material:Lron+Rubber
Packing:PP bag inside, carton box outside
Payment Terms:Western Union, L/C, T/T, MoneyGram, D/A, D/P
MOQ:Acceptable trial order
Shipping Mode:By air, by sea, by express(Fedex, UPS, DHL, TNT, etc.)
Place of Origin:Guangdong, China
Brand name:COGENG
CertifiCATEEion:ISO9001
Supply :500PCS
Decompose pictures
Here are some additional details about
Function: Throttle motors receive signals from the vehicle's electronic control unit (ECU) or engine management system. Based on these signals, the throttle motor adjusts the position of the throttle valve to control the engine's power output.
Construction: Throttle motors consist of an electric motor, a worm gear mechanism, and a position sensor. The position sensor monitors the throttle valve's position and relays the information to the ECU.
Operation: When the ECU detects the need for a change in engine power, it sends a signal to the throttle motor. The motor then moves the throttle valve, adjusting the airflow or fuel flow accordingly.
Benefits: Throttle motors offer precise control over the engine's throttle, allowing for smoother acceleration, improved fuel efficiency, and reduced emissions. They also enable advanced features such as electronic throttle control (ETC) and cruise control.
Maintenance: Throttle motors are typically designed as sealed units and do not require regular maintenance. However, if a throttle motor malfunctions, it may need to be replaced or repaired by a qualified technician.
Parts list
| NO |
Number |
Name |
Qty |
| 1 |
4257163 |
Throttle Motor |
1 |
| 3 |
4602634 |
Bracket |
2 |
| 4 |
3051015 |
Lever |
1 |
| 5 |
94-2204 |
Shaft Key |
1 |
| 8 |
14M7272 |
Nut |
4 |
| 9 |
12M7006 |
Lock Washer |
6 |
| 10 |
4257162 |
Stud |
1 |
| 11 |
4260781 |
Bushing |
2 |
| 12 |
40M7188 |
Snap Ring |
1 |
| 13 |
2030310 |
Lever |
1 |
| 14 |
4257164 |
Throttle Motor |
1 |
| 15 |
19M8553 |
Screw |
2 |
| 16 |
4254025 |
Link |
1 |
| 17 |
4254023 |
Bolt |
2 |
| 22 |
19M7164 |
Cap Screw |
1 |
| 24 |
12M7066 |
Lock Washer |
4 |
| 25 |
19M8499 |
Cap Screw |
4 |
| 26 |
40M7202 |
Snap Ring |
2 |
| 27 |
9095828 |
Spring Assembly |
1 |
| 27A |
4722815 |
Ball Joint |
2 |
| 27D |
14M7272 |
Nut |
2 |
| 27E |
12M7006 |
Lock Washer |
1 |
| 27F |
J900614 |
Bolt |
1 |
| 27G |
40M7136 |
Snap Ring |
1 |
| 28 |
4271909 |
Spring |
1 |
| 29 |
14M7273 |
Nut |
1 |
| 30 |
7024515 |
Bracket |
1 |
| 31 |
12H317 |
Lock Washer |
1 |
| 32 |
19M7938 |
Cap Screw |
4 |
| 32 |
12M7066 |
Lock Washer |
4 |
Installation decomposition diagram
