4257164 HITACH Throttle Motor
Product name: HITACH Throttle Motor
Part No: 4257164
Model Number:For EX100-2 EX200-3 EX200LC-2 EX200LC-3 EX2500 EX300LC-2 EX300LC-3 EX400LC-3C EX550LC-3 EX750-5
Material:Lron+Rubber
Packing:PP bag inside, carton box outside
Payment Terms:Western Union, L/C, T/T, MoneyGram, D/A, D/P
MOQ:Acceptable trial order
Shipping Mode:By air, by sea, by express(Fedex, UPS, DHL, TNT, etc.)
Place of Origin:Guangdong, China
Brand name:COGENG
CertifiCATEEion:ISO9001
Supply :500PCS
Decompose pictures
Here are some additional details about
The Throttle Moto plays a crucial role in controlling the throttle valve in the electronic throttle control system of these excavator models. It receives signals from various sensors, such as the Throttle Position Sensor (TPS), and adjusts the throttle valve's position accordingly.
The Throttle Motor is responsible for translating the driver's input from the accelerator pedal into precise throttle control, regulating the engine's power output. It operates within the Electronic Throttle Control (ETC) system, which uses electronic sensors and actuators instead of traditional mechanical linkages.
The compatibility of the Throttle Motor with these specific Hitachi excavator models suggests that it is designed to meet the requirements and specifications of these machines. However, it is always recommended to verify the compatibility and specific application of the Throttle Motor with the respective equipment before making a purchase or installation.
Parts list
| NO |
Number |
Name |
Qty |
| 0131 |
9095590 |
MOTORASS'Y |
1 |
| 01 |
4257163 |
MOTOR;STEP |
1 |
| 03 |
4257159 |
.BRACKET |
2 |
| 04 |
3051015 |
.LEVER |
1 |
| 05 |
94-2204 |
.KEY |
1 |
| 08 |
M500605 |
.NUT |
4 |
| 09 |
A590906 |
、WASHER;SPRING |
6 |
| 10 |
4257162 |
.PIN |
1 |
| 11 |
4260781 |
.BUSHING |
2 |
| 12 |
991337 |
RING;RETAINING |
1 |
| 13 |
2030310 |
.LEVER |
1 |
| 14 |
4257164 |
Throttle Motor |
1 |
| 15 |
M340616 |
BOLT;SOCKET |
2 |
| 16 |
4254025 |
LINK |
1 |
| 17 |
4254023 |
.PIN |
2 |
| 22 |
4257161 |
BOLT |
1 |
| 25 |
J011060 |
、BOLT;SEMS |
4 |
| 26 |
991336 |
RING;RETAINING |
2 |
| 27 |
9095828 |
SPRINGASS'Y |
1 |
| 27A |
4056017 |
JOINT;BALL |
2 |
| 27B |
4261314 |
.BUSHING |
1 |
| 27C |
4064463 |
RING;RETAINING |
1 |
| 27D |
M500605 |
..NUT |
2 |
| 27E |
4258876 |
..SPRING |
1 |
| 27F |
J010614 |
.BOLT;SEMS |
1 |
| 27G |
4266428 |
..SEAT;SPRING |
1 |
| 27H |
4278445 |
.SEAT;SPRING |
1 |
| 271 |
9737377 |
….RING |
1 |
| 27] |
4278473 |
.ROD |
1 |
| 27K |
4278446 |
..SPACER |
1 |
| 28 |
4271909 |
SPRING |
1 |
| 29 |
M500807 |
.NUT |
1 |
| 30 |
7024514 |
.BRACKET |
1 |
| 31 |
A590914 |
.WASHER;SPRING |
1 |
| 101 |
J011020 |
BOLT;SEMS |
4 |
Installation decomposition diagram
