| Specification Category | Technical Specifications |
|---|---|
| Compatible Volvo Excavators | EC210, EC210LR, EC210NLC, EC240, EC240LC, EC240LR, EC140LCM, EC290LC, EC290LR, EC360, EC360LC, EC460, EC460LC, EC150 |
| Compatible Volvo Wheel Loaders | EW170, EW180 |
| COGENG Part Number | CG-VOLVO-TM-58 |
| Replaces OEM Part Number | VOE14529290 |
| Product Type | Advanced Electronic Throttle Motor Assembly |
| Motor Technology | Brushless DC with Smart Drive Electronics |
| Operating Voltage | 24V DC Systems |
| Protection Rating | IP69K Hermetically Sealed |
| Position Sensing | Dual-Redundant Hall Effect Sensors |
| Operating Temperature | -40°C to 125°C |
| Response Time | <60ms Full Range |
| Machine Compatibility | Tested across all specified excavators and wheel loaders |
| Quality Assurance | Volvo System Integration and Performance Testing |
| Warranty | 5,000-Hour Warranty |
| NO | Number | Name | Qty |
| 1 | VOE14529228 | Bracket | 1 |
| 2 | VOE946441 | Flange screw | 4 |
| 3 | SA1127-40041 | Control Unit | 1 |
| 4 | SA9211-08000 | Washer | 4 |
| 5 | VOE946671 | Flange screw | 4 |
| 6 | VOE14501904 | Display | 1 |
| 7 | SA9211-04000 | Washer | 4 |
| 8 | SA9021-10402 | Cross recessed screw | 4 |
| 9 | SA1123-00850 | Toggle switch | 1 |
| 10 | SA1127-20140 | Box | 1 |
| 11 | VOE969422 | Six point socket screw | 2 |
| 12 | VOE955892 | Plain washer | 2 |
| 13 | VOE14529290 | Throttle Motor | 1 |
| 14 | VOE14529309 | Clip | 1 |
| 15 | VOE946471 | Flange screw | 1 |
| 16 | SA1022-01040 | Magnet | 1 |
| 17 | SA9511-12011 | O-ring | 1 |
| 18 | SA1127-30300 | Adapter | 1 |
| 19 | SA9426-20030 | Gasket | 1 |
| 20 | SA1127-00900 | Switch | 1 |
| 21 | SA1127-00611 | Sensor | 1 |
| 22 | SA1127-00500 | Cover | 1 |
