| Category | Specification |
|---|---|
| COGENG Set Number | CG-KOB-SET-YN35V00004F2-00005F1-00005F2 |
| OEM References | YN35V00004F2, YN35V00005F1, YN35V00005F2 |
| Compatible Models | SK100, SK120, SK200 |
| Machine Weight Range | 1-2 Ton Compact Excavators |
| Valve Type | Hydraulic Solenoid |
| Pressure Rating | Meets Kobelco Compact Specifications |
| Response Time | < 40ms |
| Voltage Rating | 12V DC System |
| Design Feature | Compact Size Optimized |
| Quality Validation | 100% Individual & Set Testing |
| Warranty Coverage | 18-Month Limited Warranty |
| NO | Number | Name | Qty |
| YN35V00001F1 | VALVE | AR | |
| 1 | NSS | NOT SERVICED SEPARATELY MANIFOLD | 1 |
| 2 | YN35V00005F1 | SOLENOID VALVE | 5 |
| 3 | YN35V00005F2 | SOLENOID VALVE | 1 |
| 4 | YN35V00004F2 | SOLENOID VALVE | 5 |
| 5 | YN30V00001S156 | PLUG | 1 |
| 6 | ZD12P01400 | 0-RING | 1 |
| 7 | 2441U722S490 | PLUG | 8 |
| 8 | NSS | NOT SERVICED SEPARATELY NAME PLATE | 1 |
| 9 | NSS | NOT SERVICED SEPARATELY SCREW | 2 |
Complete hydraulic system depressurization required
Install all three valves as complete set for optimal performance
Follow compact model specific routing and mounting procedures
Ensure proper clearance in tight compact equipment spaces
Test all hydraulic functions before returning to service
